Features:

1,This equipent can produce ultra-thin type, cotton core type economical sanitary napkin.

2,Surface layer-non woven,PE film,packing film, automatic splicing, auto material tension control, automaticrectification and auto reject wasted products.

3, Auto stop machine when breakdowntake place.

4, Knife rest material used the 45 quenched and tempered steel,extend the service life of cutter

5,High speed pulverizer speed can reach 350KG per hours, Teeth-like crusher can take treated or untreated rolled pulp.

6, Human machine interface, Can realize multi-function parameter setting, alarm and query function

7,The machine equipment with Body protective door.

Technical parameters:

Design speed: 140M/min

 actual velocity: 350-400pcs/min

Product specifications:produce one size(the length can be adjusted by the customer)

installed capacity:140kw(with Hot melt glue machine,one time forming)

power: four wire three phase, 380V 50HZ

baric minimum: ＞0.6mpa , 1.3m3/min

Gross Weight:about 35 ton

Noise: <80db (A)

Machine size:L*W*H 22x5x3 M

 Fittings Selection:

1: Perfume spray device

2: Sanitary napkin core printing device

3:ADL conducting layer device

4: Finishing piece number machine
